Stamping / Stacking Robot SDCX RMD-300/200/160/120/35/08/110/20/50

A takaice gabatarwar samfurin

The stamping robot ana amfani da ko'ina don stacking, destacking, sufuri da sauran ayyuka a cikin filayen shiryawa, abin sha, sinadaran masana'antu, abinci, da dai sauransu, samar da masu amfani da cikakken sa na sauri, aminci, m, daidai da sakawa aiki mafita.

TUNTUBE MU

Cikakken Bayani

Tags samfurin

Ma'aunin Fasaha

Model No.	Digiri na 'Yanci	Yanayin tuƙi	Kayan Aiki (KG)	Matsakaicin daidaitawa mai maimaitawa (mm)	Kewayon motsi (°)				Matsakaicin gudun (°/s)				Ƙunƙarar nauyin da aka ba da izini na wuyan hannu (kg·m²)	bugun madauwari (zagaye/sa'a)	Radius na motsi (mm)	Nauyin Gida (kg)
Model No.	Digiri na 'Yanci	Yanayin tuƙi	Kayan Aiki (KG)	Matsakaicin daidaitawa mai maimaitawa (mm)	J1	J2	J3	J4	J1	J2	J3	J4		bugun madauwari (zagaye/sa'a)	Radius na motsi (mm)	Nauyin Gida (kg)
Saukewa: SDCX-RMD300	4	AC servo drive	300	± 0.5	± 180	± + 100-44	± +121-15	± 360	85	90	100	190	134	1000^③	3150	1500
Saukewa: SDCX-RMD200	4	AC servo drive	200	± 0.3	± 180	± + 100-44	± +121-15	± 360	105	107	114	242	78	1300^③	3150	1500
Saukewa: SDCX-RMD160	4	AC servo drive	160	± 0.3	± 180	± + 100-44	± +121-15	± 360	123	123	128	300	78	1500^③	3150	1500
Saukewa: SDCX-RMD120	4	AC servo drive	120	± 0.3	± 180	± + 100-44	± +121-15	± 360	128	126	135	300	78	1560^③	3150	1500
Saukewa: SDCX-RMD50	4	AC servo drive	50	± 0.2	± 178	± +90-40	± +65-78	± 360	171	171	171	222	4.5	1700^②	2040	660
Saukewa: SDCX-RMD20	4	AC servo drive	20	± 0.08	± 1170	± +115-25	± +70-90	± 360	170	170	185	330	0.51	1780^①	1720	256
Saukewa: SDCX-RMD08	4	AC servo drive	8	± 0.08	± 170	± +90-40	± +68-90	± 360	251	195	195	367.5	0.25	1800^①	1433	180

Bayani:

① Waƙar gwajin tana da tsayin 150mm da faɗin 1000mm, kuma ainihin lokacin sake zagayowar yana shafar yanayin aiki na ainihi;

② Waƙar gwajin tana da tsayin 200mm da faɗin 1000mm, kuma ainihin lokacin sake zagayowar ya shafi ainihin yanayin aiki;

③ Waƙar gwajin tana da tsayin 400mm da faɗin 2000mm, kuma ainihin lokacin sake zagayowar ya shafi ainihin yanayin aiki;

Guji hulɗa da iskar gas da ruwa masu ƙonewa, fashewa da lalata;Yi don kada a yayyafa shi da ruwa, mai da ƙura;Nisanta daga tushen hayaniyar lantarki (plasma)
